Product Data:
| Model | HKM-SL1 |
| Name | Single Door Steel Locker |
| Product Size | H1850 * W380 * D450mm |
| Package Size | H1880 * W480 * D78mm = 0.0704CBM |
| Loading Qty | 965 Pcs/40’HQ, 397 Pcs/20’GP |
| Material | Heavy-gauge cold-rolled steel plate. |
| Pre-treatment | Water wash, chemical wash, phosphating. |
| Finish | Durable electrostatic powder coating. |
| Colour | Classic grey, two-tone option, or other customized colours. |
| Fittings | Chrome-coated rod, index holder, keyed cam lock, or padlock latch. |
| Accessories | 2 keys, assembly screws. |
- Knock-down and easy-assembling construction.
- Different locks available as options.
- Different colors available as options.
- Different air ventilation options available.
- Standing legs available.
- Sloping top available.
- Master key available.
- Core-removable lock available.
6 steps to assemble the Single Door Steel Locker.
- Connect the left side plate with the back plate using self-tapping screws (5×12).
- Connect the right side plate with the back plate.
- Fix the door frame onto both of the side plates.
- Install the top and bottom plates respectively.
- Install the shelf and hanging rod.
- Adjust each part until it fits well after installation.
