Product Data:
| Model | HKM-GDC2 |
| Name | Glass Door Office Cupboard |
| Product Size | H1850 * W900 * D400mm |
| Package Size | H1880 * W930 * D75mm = 0.1311CBM |
| Loading Qty | 519 Pcs/40’HQ, 214 Pcs/20’GP |
| Material | Heavy-gauge cold-rolled steel plate. |
| Pre-treatment | Water wash, chemical wash, phosphating. |
| Finish | Durable electrostatic powder coating. |
| Colour | Classic grey, two-tone option, or other customized colours. |
| Fittings | 3 shelves. |
| Accessories | 4 keys, assembly screws. |
- Knock-down and easy-assembling construction.
- Different locks available as options.
- Different colors available as options.
- Adjustable shelves.
- With huge load capacity for each shelf.
- Reinforced doors for strength.
- Master key available.
- Core-removable lock available.
6 steps to assemble the Glass Door Office Cupboard.
- Connect the left side plate with the back plate using self-tapping screws (5×12).
- Connect the right side plate with the back plate.
- Fix the door frame onto both of the side plates.
- Install the top and bottom plates respectively.
- Install the shelves.
- Adjust each part until it fits well after installation.
